DT200i / DT230i

More Functionality in Less Space !

Description
Additional information

The DT200i series is a cleverly conceived design that combines multiple capabilities into a single platform. It provides 203 dpi or 300 dpi printing resolution and the DT200i+ features a 2.4-inch color display for easy operation. An extensive range of optional accessories are also available, and the DT200i even supports linerless media printing. This series can fulfill all of your direct thermal printing requirements.

Specially Designed Mechanism
Compatible Interface
Large Memory
User-Friendly Operation
2.4” Color LCD & Stand-Alone Operation

Print Method	Direct Thermal
Resolution	203 dpi (8 dots/ mm), 300 dpi (12 dots/ mm)
Print Speed	5 IPS (127 mm / s), 7 IPS (178 mm / s)
Print Width	2,24” (57 mm), 4,25” (108 mm)
Print Length	Min. 0,16” (4 mm); Max. 30“(762 mm), Min. 0,16” (4 mm); Max. 68” (1727 mm)
Processor	32 Bit RISC CPU
Memory	128 MB Flash (60 MB for user storage), 32 MB SDRAM
Interfaces	Ethernet 10/100 Mbps, Serial port: RS-232 (DB-9), USB 2.0 (B-Type), USB Host (A-Type)
Ribbon	N/A
Control Panel	Calibration button, Calibration button, Color TFT LCD with navigation button, Function Key : FEED, Power on/off
Series	DT Series
